Gate
Ref
Measurement
Symbol
Meaning
DAC
Peak
%DAC(U)
DAC^%(U)
Peak measurement, in %, relative to
DAC curve. Uncorrected if the gain
changed. Use with care
DAC
Peak
dB DAC(C)
DAC^dB(C)
Peak measurement, in dB, relative to
DAC curve. Corrected if the gain
changed
DAC
Peak
dB DAC(U)
DAC^dB(U)
Peak measurement, in dB, relative to
DAC curve. Uncorrected if the gain
changed. Use with care
DGS
Peak
%DGS(C)
DGS^%(C)
Peak measurement, in %, relative to
DGS curve. Corrected if the gain
changed
DGS
Peak
%DGS(U)
DGS^%(U)
Peak measurement, in %, relative to
DGS curve. Uncorrected if the gain
changed. Use with care
DGS
Peak
dB DGS(C)
DGS^dB(C)
Peak measurement, in dB, relative to
DGS curve. Corrected if the gain
changed
DGS
Peak
dB DGS(U)
DGS^dB(U)
Peak measurement, in dB, relative to
DGS curve. Uncorrected if the gain
changed. Use with care
DGS
Peak
ERS
GX^ ERS
Peak Measurement, in ERS (Equivalent
Reflector Size), relative to DGS curve.
Corrected if gain changes.
G1-G2
Peak
Sound Path
G1-G2^⇘
Difference, in sound path distance,
between gate 1 peak and gate 2 peak
measurements
G1-G2
Peak
Depth
G1-G2^⇓
Difference, in depth, between gate 1
peak and gate 2 peak measurements
G1-G2
Peak
True Depth
G1-G2⇓⊻
Difference, in true depth, between
gate 1 peak and gate 2 peak
measurements
G1-G2
Peak
Surface
Distance
G1-G2^⇒
Difference, in surface distance,
between gate 1 peak and gate 2 peak
measurements
G3-G4
Peak
Sound Path
G3-G4^⇘
Difference, in sound path distance,
between gate 3 peak and gate 3 peak
measurements
