Wave User Manual 87
Version 4
At this point, the report is not saved. Adjustments are still possible. All you have to do is
click on the back arrow to make the changes.
The following table shows the sections displayed according to the pagination of the
report.
Table 31 – Breaking down sections of a typical report
Content
Note
Header
• Company Information
First page
• Customer
• Equipment Specifications
1
• Material
• Description
2
• Certification
1. This section is automatically
generated with the information
intrinsically linked to the device,
such as the serial number or the
software version.
2. If the description is too long, it will
automatically appear on the second
page.
Second page
3
• Screenshot(s)
3
• Caption(s)
4
3. If there are several images selected,
other pages will be created.
However, the screenshot will never
be on the first or last page of the
report.
4. The caption corresponds to the title
of the screenshot.
Last page
• Code
• Gain and Amplitude
• Sizing Method
5
• Transducer and Wedge
• Calibration Block
5. If the source does not have an
associated sizing method, this
section will not be displayed.
