II-95
* The layout sequence of the ES can be changed using the Rotation button on
the tool bar.
Press the L key using the Rotation button.
The same layout is
displayed regardless
of which button is
selected.
Select any four of the checkboxes.
Select Display using the menu button, and
then press the L key using Display Toolbar.
When selecting a 4-window screen structure (Four transducers must
be connected).
Note: The fish length graph, TS graph, and trace graph are valid only at
frequencies of 38, 70, and 120 kHz.
