II-26
2-10-1-2 FIX SEA BOTTOM
Use the FIX SEA BOTTOM function when the fish to be measured are near the
sea bottom. To use FIX SEA BOTTOM, follow the procedure shown in Fig. 2-31
below.
Display the FISH LENGTH GRAPH
(For the displaying procedure of the FISH LENGTH GRAPH, refer to Section 2-7).
The FISH LENGTH GRAPH SETTING screen is displayed and selects the
SHOW DETAIL.
Press the L key on the GRAPH Setting.
1
2
3-1
FISH LENGTH GRAPH SETTING
screen is displayed.
Display the FISH
LENGTH GRAPH.
Check the GRAPH
SETTING.
1
2
3
3-2
SHOW DETAIL screen is select
