II-27
Distance borderline in the fish length graph display of the fixed sea bottom
Fig. 2-31 The procedure for displaying the FISH LENGTH GRAPH of FIX SEA BOTTOM
* This function cannot be used when sea bottom detection is impossible.
Using the L key, set the depth from
the sea bottom (from 5 to100m).
Press the OK button.
5-1
5-2
The distance from
the sea bottom you
set.
5
FIX SEA BOTTOM on the FISH LENGTH GRAPH SETTING becomes
active. Set the distance from the sea bottom, and press the OK button. Then,
the fish length of FIX SEA BOTTOM is displayed.
Select FIX SEA BOTTOM.
Select FIX SEA BOTTOM from SELECTION METHOD.
4
4
Distance borderline in
the fish length graph
display
