II-28
2-10-1-3 DEPTH
DEPTH is a useful function when the fish to be measured gather in a linear
shape.
To use the DEPTH function, follow the procedure in Fig. 2-32 below.
The FISH LENGTH GRAPH is displayed.
(For displaying procedure of the fish length, refer to Section 2-7).
Press the L key on the FISH LENGTH GRAPH.
The FISH LENGTH GRAPH SETTING screen is displayed.
Display CURSOR CONTROL in the shortcut menu. Then, turn ON the H CURSOR button,
and set the CURSOR DEPTH.
1-1
Display the
CURSOR
CONTROL
screen.
1-3
Set the
CURSOR
DEPTH.
Select the H CURSOR
button.
1-2
Check the
GRAPH SETTING.
Display the FISH
LENGTH GRAPH.
2
3
1
2
3
4
