II-29
* When the H CURSOR button is turned ON in (1), DEPTH of SELECTION
METHOD becomes active and selectable.
Fig. 2-32 The procedure for displaying the FISH LENGTH GRAPH of DEPTH
Press the L key on
the radio button of DEPTH.
Press the OK button.
Select DEPTH from the SELECTION METHOD, and press the OK button.
Then, the FISH LENGTH GRAPH at the depth set by the H CURSOR will be
displayed.
4
The FISH LENGTH GRAPH
SETTING screen is displayed.
5-1
5-2
The area
encircled by the
red box is
displayed in the
FISH LENGTH
GRAPH.
5
