II-30
2-10-1-4 FULL SCREEN
FULL SCREEN function is useful when the fish to be measured are in the
entire ES image.
To use the FULL SCREEN function, follow the procedure given in Fig. 2-33
below.
Select FULL SCREEN.
Press the OK button.
Display the FISH LENGTH GRAPH.
(For displaying the FISH LENGTH GRAPH, refer to Section 2-7)
Press the L key on the FISH LENGTH GRAPH.
The FISH LENGTH GRAPH display screen is displayed.
Select FULL SCREEN from the SELECTION METHOD, and press the OK
button to display the FISH LENGTH GRAPH in FULL SCREEN.
3
FISH LENGTH GRAPH SETTING
screen is displayed.
4-1
4-
Display the FISH
LENGTH GRAPH.
Check the GRAPH
SETTING button.
1
2
1
2
3
4
