14
Port Name
Connection
Function
1-4 (N8NXP)
1-16
(N16NXP)
Sensor Input
Sensor input ports
NO
Relay output
Normally open terminal
C
Common terminal
CTRL 12V
Relay output /
Power output
Used as the last relay output. Also supplies
12VDC power when there is no alarm.
+12V
Power output
12V DC power output. Can be used for devices
that require less than 1A.
