STEP AS380 Series User Manual

Shanghai STEP Electric Corporation
Chapter 5 Operator
100
5
th
time：Y16-Y31
6
th
time：TY0-TY15
6
Err.Code
Direction Up
Auto 4Flr.
=============
status、floor、direction
7
Err.info.
Pulse 889
location 2196
=============
Elevator hoist way location、encoder pulse code
8
Err.Info.
FBK spd. 0.80m/s
datum spd. 0.79m/s
Datum speed、feedback speed
3) Special failure information check, according to the failure determine whether there is a
special information to this failure, or else cannot enter by pressing ENTER, for example: over
speed failure can check 6 groups information, as below：
Table 5.20 failure feedback dispaly
Step
Key
Display on operator
Remarks
-
Err.Info.
06-10-02 15:30
Over speed
Over speed failure
1
Eenter
Datum FBK
799 998
899 1156
812 1032
Inter special information check
2
Eenter
Datum FBK
789 977
802 1003
800 999
and can be used to paging checking different failure
information
3
ESC
Err.Info.
06-10-02 15:30
Over speed
Press
ESC
exit checking
4）self-study failure
a）if self-study failure opened，elevator stop self-studying，failure displayed in main monitor
display，failure checking measure is as above；
b）if there is no failure after self-studying，operator jump into reminder display as below
