Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 5 Operator
101
Table 5.21 self-study display
Step
Key
Display on operator
Remarks
-
auto Simplex
Door Locked
1 Floor 0.00m/s
=== 00000018 ===
1
Flr. 8
Down Sw. 2Lv.
2Flr.Max. 4120
8Flr.Min. 1290
2
Eenter
Study Success
ESC: Back
ENTER: Affirm
If the self-study data is the same as the practical data, self-study
successesPress
Eenter
to affirm. Or else press
ESC
back.
ESC
Study Fail
ESC: Back
ENTER: Affirm
3
Eenter
auto Simplex
Door Locked
1 Floor 0.00m/s
=== 00000018 ===
Press
Eenter
back to the last display
Press
ESC
back to <1>
cif there is a failure need to remind information after self-studyoperator jump into remind
display as below
Table 5.22 self-study done display
Step
Key
Display on operator
Remarks
-
auto Simplex
Door Locked
1 Floor 0.00m/s
=== 00000018 ===
1
Flr. 8
Down Sw. 2Lv.
2Flr.Max. 4120
8Flr.Min. 1290
2
Eenter
or
ESC
Noted
2Flr. high too much
height 8966mm
Up/Dn change page
