STEP AS380 Series User Manual

Shanghai STEP Electric Corporation
Chapter 6 Introduction to the supporting products
108
Socket No
Port No
Definition
Remark
4
CANL blue
JP2
Connecting car top extension board
JP3
1
Out put JP3.2-JP3.3 common port
2
Output HY0，down arrival gong
3
Output HY1， upper arrival gong
4
Output 0V
5
Output 24V
JP4
1
Input JP4.2-JP4.3 common port
2
Input HX0，front door close in place
Default NC
3
Input HX1，front door open in place
Default NC
4
Output JP4.5-JP4.7common port
5
Output HY2，front door forced close output
6
Output HY3 ， front door close signal
output
7
Output HY4， front door open signal output
JP5
1
Input JP5.2-JP5.3 common port，0V
2
Input HX2，front door safety edge
Default NC
3
Input HX3，front door light curtain
Default NO
JP6
1
Input JP6.2-JP6.4 common port，0V
2
Input HX4，light load
Default NO
3
Input HX5，full load
Default NO
4
Input HX6，overload
Default NC
JP7
1
Parallel voice port D0, LSB
2
Parallel voice port D1
3
Parallel voice port D2
4
Parallel voice port D3
5
Parallel voice port D4
6
Parallel voice port D5
7
Parallel voice port D6
8
Parallel voice port D7, MSB
9
Common port 0V
10
Common port ＋24V
JP8
1
JP8.2 common port
2
Output HY5，light fan relay
DB1
Program burning record port
SW1
SW1.1
simultaneously turn on and CAN terminal
resistor is connected, simultaneously turn
off and terminal resistor disconnected
SW1.2
SW2
SW2.1
simultaneously turn on and enter into the
program recording status, simultaneously
turn off and return to normal running status
SW2.2
