Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 6 Introduction to the supporting products
Note:
1) The JP 7 port of SM-02/H outputs eight-bit binary coding pulse signals, triggering voice
landing forecast during deceleration of car for stop, one second for every pulse output. The
eight-bit output is in the mode of transistors with open loop in the collector and shared anode,
output voltage DC24V, current capacity 50mA. The 8-bit binary coding provides as many as
255 output status in accordance with STEP WORD BANK for display, namely, supposing t that
user set B1 for the first floor display, the corresponding display code is 60. The JP7 output
signal is to transform the decimal bit of 60 into binary bit before outputting. The words‖ we
now arrive at B1 floor‖ are broadcasted by decoding that binary signal. At present 0-247 are
processed by the definition of the word bank for display（see the List of Display Codes in
6.5.10） whereas the codes of 248-255 are defined as following:
(248) 11111000: The elevator door close and the signal sent when the elevator is at
main landing and is about to move upward
(249) 11111001: the signal sent when elevator is in fire alarming status.
(250) 11111010: The signal appears when the door-closing position limit switch turns
from OFF to ON status during the door-opening.
(251) 11111011: The signal appears when the door-opening position limit switch
turns from OFF to ON status during the door-closing.
(252) 11111100： Overload alarming
(253) 11111101： Door opening in place and then forecast next moving direction as
upward
(254) 11111110：Door opening in place and then forecast next moving direction as
downward
(255) 11111111：To be defined.
2． Wiring and Connection
Car top controller and connection between power supply and communication bus
The car controller with power supply and CAN BUS is lined in from JP1, of which
JP1.1 and JP1.2 are for TXV+ and TXV-，JP1.3 and JP1.4 for TXA+ and TXA-
respectively. TXV+, TXV- are power input DC24V; TXA+ and TXA- are
communication lines which must be 4-wire Twisted Pairs.
Car top controller input signal connection
Car top controller is mainly responsible for collecting part of switch-generated data
signal from car top and bottom, and transmit these signal status into main controller
through CAN bus. The switch signal is such as door-open/close input, door-open/close
in place, safety edge, overload, full load and etc.
connection of output signal of car top controller
Car controller control the relay output with the signals transmitted by CAN bus from
main controller. Its relay output control the arrival gong relay, lighting relay and etc for
function such as arrival forecast, energy-saving lighting control
