Chapter 7 Parameter Table of Integrated Drive Controller
Time section floor blockade
closure time set
Service floor 1 (Floor 1~ 16)
when NS-SW function is set.
Service floor 2 (Floor 17~ 32)
when NS-SW function is set.
Service floor 3 (Floor 33~ 48)
when NS-SW function is set.
Service floor 4 (Floor 49~ 64)
when NS-SW function is set.
Time of delay release of the main
contactor (after enabled)
Protection of contact detection
Lighting delay (fans turned off
automatically, delay lighting)
0: do not turn off the lights
high-voltage input detection with
or without hall door lock
With or without lock relay contact
detection
Whether the manual removal of
error instruction activated
The function of floor blocking for
a time slot
Bit0: 1: block instruction
Bit1: 1: block upward call
Bit2: 1: block downward call
Choose whether the back-up
power continues running after
returning to the base in case of
single elevator or parallel
connection
0: stop running
1: may continue running
See the manual for more detailed
explanation
Special control of door operation
Bit0: 1: door closed during
Ispection
Bit1: 1: door closed during debug
running
Bit2: 1: door opened at the base
station for the elevator
Bit3: 1: whether to open the door
by LED operator
Elevator No. with IC card
service
Selection of upward and
downward callus by IC card
IC card function in the car
corresponding to IC card
swiping need on Floor 1～16
IC card function in the car
corresponding to IC card
swiping need on Floor 17～
32
