STEP AS380 Series User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 9 Faults and Solutions
233
Code
Description
Fault Cause Analysis
switch on the single level in the well learning
Check the operation: the position of the downward deceleration switch on the
single level is 150mm lower than the position of the downward deceleration switch
on the single level in the well learning
Check at stop: the position of the downward deceleration switch on the single
level is 100mm higher than the position of the downward deceleration switch on
the single level in the well learning
Check at stop: the position of the downward deceleration switch on the single
level is 150mm lower than the position of the downward deceleration switch on
the single level in the well learning, and the deceleration switch on the single level
is not in action
In automatic operation, the upper and lower limit switches are in action at the same
time and the elevator is not at the lowest level
12
Dislocation of
upward deceleration switch 2
Check after self study or with power on: the position of the upward deceleration
switch on the double level is 3/5 higher than the story height of the switch floor
Check the operation: the position of the upward deceleration switch on the double
level is 150mm lower than the position of the upward deceleration switch on the
double level in the well learning
Check the operation: the position of the upward deceleration switch on the double
level is 250mm higher than the position of the upward deceleration switch on the
double level in the well learning
Check at stop: the position of the upward deceleration switch on the double level is
150mm lower than the position of the upward deceleration switch on the double
level in the well learning
Check at stop: the position of the upward deceleration switch on the double level is
200mm higher than the position of the upward deceleration switch on the double
level in the well learning, and the deceleration switch on the double level is not in
action
Only one-grade deceleration switch installed, but two-grade deceleration switch
configured (See F182)
13
Dislocation of
downward deceleration switch 2
Check after self study or with power on: the position of the downward deceleration
switch on the double level is 3/5 higher than the story height of the switch floor
Check the operation: the position of the downward deceleration switch on the
double level is 150mm higher than the position of the downward deceleration
switch on the double level in the well learning
Check the operation: the position of the downward deceleration switch on the
double level is 250mm lower than the position of the downward deceleration
switch on the double level in the well learning
Check at stop: the position of the downward deceleration switch on the double
level is 150mm higher than the position of the downward deceleration switch on
the double level in the well learning
Check at stop: the position of the downward deceleration switch on the double
level is 200mm lower than the position of the downward deceleration switch on
the double level in the well learning, and the deceleration switch on the double
level is not in action
Only one-grade deceleration switch installed, but two-grade deceleration switch
configured (See F182)
14
Dislocation of
upward deceleration switch 3
Check after self study or with power on: the position of the upward deceleration
switch on three levels is 3/5 higher than the story height of the switch floor
Check the operation: the position of the upward deceleration switch on three
levels is 250mm lower than the position of the upward deceleration switch on three
levels in the well learning
Check the operation: the position of the upward deceleration switch on three
levels is 300mm higher than the position of the upward deceleration switch on
three levels in the well learning
Check at stop: the position of the upward deceleration switch on three levels is
250mm lower than the position of the upward deceleration switch on three levels
in the well learning
Check at stop: the position of the upward deceleration switch on three levels is
250mm higher than the position of the upward deceleration switch on three levels
