STEP AS380 Series User Manual

Shanghai STEP Electric Corporation
Chapter 9 Faults and Solutions
234
Code
Description
Fault Cause Analysis
in the well learning, and the deceleration switch on three levels is not in action
Only one-grade or two-grade deceleration switch installed, but three-grade
deceleration switch configured (See F182)
15
Dislocation of
downward deceleration switch 3
Check after self study or with power on: the position of the downward deceleration
switch on three levels is 3/5 higher than the story height of the switch floor
Check the operation: the position of the downward deceleration switch on three
levels is 250mm higher than the position of the downward deceleration switch on
three levels in the well learning
Check the operation: the position of the downward deceleration switch on three
levels is 300mm lower than the position of the downward deceleration switch on
three levels in the well learning
Check at stop: the position of the downward deceleration switch on three levels is
250mm higher than the position of the downward deceleration switch on three
levels in the well learning
Check at stop: the position of the downward deceleration switch on three levels is
250mm lower than the position of the downward deceleration switch on three
levels in the well learning, and the deceleration switch on three levels is not in
action
Only one-grade or two-grade deceleration switch installed, but three-grade
deceleration switch configured (See F182)
16
Dislocation of
upward deceleration switch 4
Check after self study or with power on: the position of the upward deceleration
switch on four levels is 3/5 higher than the story height of the switch floor
Check the operation: the position of the upward deceleration switch on the double
level is 150mm lower than the position of the upward deceleration switch on the
double level in the well learning
Check the operation: the position of the upward deceleration switch on the double
level is 250mm higher than the position of the upward deceleration switch on the
double level in the well learning
Check at stop: the position of the upward deceleration switch on the double level is
150mm lower than the position of the upward deceleration switch on the double
level in the well learning
Check at stop: the position of the upward deceleration switch on the double level is
200mm higher than the position of the upward deceleration switch on the double
level in the well learning, and the deceleration switch on the double level is not in
action
Only one-grade, two-grade or three-grade deceleration switch installed, but
four-grade deceleration switch configured (See F182)
17
Dislocation of
downward deceleration switch 4
Check after self study or with power on: the position of the downward deceleration
switch on the double levels is 3/5 lower than the story height of the switch floor
Check the operation: the position of the downward deceleration switch on the
double level is 150mm higher than the position of the downward deceleration
switch on the double level in the well learning
Check the operation: the position of the downward deceleration switch on the
double level is 250mm lower than the position of the downward deceleration
switch on the double level in the well learning
Check at stop: the position of the downward deceleration switch on the double
level is 150mm higher than the position of the downward deceleration switch on
the double level in the well learning
Check at stop: the position of the downward deceleration switch on the double
level is 200mm lower than the position of the downward deceleration switch on
the double level in the well learning, and the deceleration switch on the double
level is not in action
Only one-grade, two-grade or three-grade deceleration switch installed, but
four-grade deceleration switch configured (See F182)
19
Door open/close limit failure
At automatic mode, door open limit switch and door close limit switch are in
action at the same time with time-out for 1.5s
20
Slip protection failure
In operation, the leveling switch is not in action for over the time set in F62
(anti-slip time), except during Inspection
