STEP AS380 Series User Manual

Shanghai STEP Electric Corporation
Appendix B Para. Fault List Summary
276
Only one-grade or two-grade deceleration switch installed, but three-grade
deceleration switch configured (See F182)
15
Dislocation of
downward deceleration switch 3
Check after self study or with power on: the position of the downward
deceleration switch on three levels is 3/5 higher than the story height of the
switch floor
Check the operation: the position of the downward deceleration switch on
three levels is 250mm higher than the position of the downward deceleration
switch on three levels in the well learning
Check the operation: the position of the downward deceleration switch on
three levels is 300mm lower than the position of the downward deceleration
switch on three levels in the well learning
Check at stop: the position of the downward deceleration switch on three
levels is 250mm higher than the position of the downward deceleration
switch on three levels in the well learning
Check at stop: the position of the downward deceleration switch on three
levels is 250mm lower than the position of the downward deceleration
switch on three levels in the well learning, and the deceleration switch on
three levels is not in action
Only one-grade or two-grade deceleration switch installed, but three-grade
deceleration switch configured (See F182)
16
Dislocation of
upward deceleration switch 4
Check after self study or with power on: the position of the upward
deceleration switch on four levels is 3/5 higher than the story height of the
switch floor
Check the operation: the position of the upward deceleration switch on the
double level is 150mm lower than the position of the upward deceleration
switch on the double level in the well learning
Check the operation: the position of the upward deceleration switch on the
double level is 250mm higher than the position of the upward deceleration
switch on the double level in the well learning
Check at stop: the position of the upward deceleration switch on the double
level is 150mm lower than the position of the upward deceleration switch on
the double level in the well learning
Check at stop: the position of the upward deceleration switch on the double
level is 200mm higher than the position of the upward deceleration switch
on the double level in the well learning, and the deceleration switch on the
double level is not in action
Only one-grade, two-grade or three-grade deceleration switch installed, but
four-grade deceleration switch configured (See F182)
17
Dislocation of
downward deceleration switch 4
Check after self study or with power on: the position of the downward
deceleration switch on the double levels is 3/5 lower than the story height of
the switch floor
Check the operation: the position of the downward deceleration switch on the
double level is 150mm higher than the position of the downward
