Instruction Manual for AS380 Series Elevator Integrated Drive Controller
277
Appendix B Para. Fault List Summary
deceleration switch on the double level in the well learning
Check the operation: the position of the downward deceleration switch on the
double level is 250mm lower than the position of the downward deceleration
switch on the double level in the well learning
Check at stop: the position of the downward deceleration switch on the
double level is 150mm higher than the position of the downward
deceleration switch on the double level in the well learning
Check at stop: the position of the downward deceleration switch on the
double level is 200mm lower than the position of the downward deceleration
switch on the double level in the well learning, and the deceleration switch
on the double level is not in action
Only one-grade, two-grade or three-grade deceleration switch installed, but
four-grade deceleration switch configured (See F182)
19
Door open/close limit failure
At automatic mode, door open limit switch and door close limit switch are in
action at the same time with time-out for 1.5s
20
Slip protection failure
In operation, the leveling switch is not in action for over the time set in F62
(anti-slip time), except during Inspection
21
Motor overheating
Input signal at motor overheating point
22
Motor reverse failure
Skid for consecutive 0.5 seconds (upward speed feedback<-150mm,
downward speed feedback>150mm)
23
Elevator overspeed failure
Failure 23 reported when speed feedback value is greater than allowable
speed for 0.1 seconds
When the given speed is less than 1m / s, allowable speed= given speed
+0.25 m / s
When the given speed is greater than 1m / s, allowable speed= given speed
*1.25
Maximum allowable speed < rated speed * 108%
When terminal level runs at a decelerating speed of 0.8m/s
2
, Failure 23
reported when speed feedback value is greater than allowable speed for 0.1
seconds
24
Elevator over-low speed
Failure 24 reported when speed feedback value is less than allowable speed
for 0.5 seconds
When the given speed is less than 0.5m / s, allowable speed= given speed
-0.25 m / s
When the given speed is greater than 0.5m / s, allowable speed= given speed
*0.5
27
Sensor failure for upper
leveling floor
After high-speed operation stops, the sensor for upper leveling floor is not
in action.
