STEP AS380 Series User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
43
Chapter 4 The Wiring Of Elevator integrated Drive Controller
JP1.4
X22
Hall door lock circuit inspection positive
voltage port，110V/220V input
Input
JP1.5
XCOM
X20-X22 input signal common port 0V,
internally connected to JP1.1
JP2
JP2.1
Y0
Band brake contactor output
Output
JP2.2
Y1
Band brake strong contactor output
Output
JP2.3
Y2
Main contactor output
Output
JP2.4
COM1
Output relay Y0-Y3 common port
JP3
JP3.1
Y3
Door pre-opening relay
Output
JP3.2
Y4
blackout emergency stop leveling completion
signal output
Output
JP3.3
COM2
output relay Y3-Y4 common port
JP3.4
Y5
firefighting signal output
Output
JP3.5
COM3
output relay Y5 common port
JP3.6
Y6
reserved ,standby
Output
JP3.7
COM4
output relay Y6 common port
JP4
JP4.1
0V
0V DC
JP4.2
CAN0H
instruction serial communication signal port
（TXA0+）
JP4.3
CAN0L
instruction serial communication signal port
（TXA0-）
JP5
JP5.1
0V
0V DC
JP5.2
CAN1H
parallel connection serial communication signal
port（TXA1+）
JP5.3
CAN1L
parallel connection serial communication signal
port（TXA1-）
JP6
JP6.1
0V
quarantine OV DC
JP6.2
CAN2H
Community monitoring （TXA2+）
JP6.3
CAN2L
Community monitoring（TXA2-）
JP7
JP7.1
G5VIO
Isolating power 0V
JP7.2
+5VIO
Isolating power +5V
JP7.3
Empty slot，TBD
JP7.4
G24VIO
opt coupler input shield power 0V
JP7.5
+24VIO
opt coupler input shield power +24V
JP8
JP8.1
X0
Inspection signal 1 ， disconnection as
inspection ， X0 and X1 all connected as
automatic
Input
Normal
close
JP8.2
X1
inspection signal 2, disconnection as inspection,
X0 and X1 all connected as automatic
Input
Normal
close
JP8.3
X2
move up signal ,inspection, inch moving up,
attendant, move up and change direction
Input
