Chapter 4 The Wiring Of Elevator integrated Drive Controller
JP8.4
X3
move down, inspection, inching move down,
attendant, move down and change direction
Input
JP8.5
X4
upward No 1 terminal deceleration switch
Input
Normal
close
JP8.6
X5
Downward No 1 terminal deceleration switch
Input
Normal
close
JP8.7
X6
upper leveling switch
Input
JP8.8
X7
under leveling switch
Input
JP8.9
X8
motor power supply contactor inspection
Input
Normal
close
JP8.10
X9
band brake contactor inspection
Input
Normal
close
JP9
JP9.1
X10
left band brake switch Inspection
Input
JP9.2
X11
right band brake switch inspection
Input
JP9.3
X12
motor temperature inspection signal
Input
JP9.4
X13
door pre-opening relay inspection
Input
JP9.5
X14
door zone signal inspection
Input
JP9.6
X15
firefight return/ firemen switch ( parameter
selection)
Input
JP9.7
X16
blackout emergency leveling input/earthquake/
building backup power supply( parameter
selection)
Input
JP9.8
X17
door interlock circuit relay inspection
Input
Normal
close
JP9.9
X18
upward No 2 terminal deceleration switch
Input
JP9.10
X19
downward No 2 terminal deceleration switch
Input
JP10
JP10.1
+24VIO
input isolating power supply +24v, internally
connect to JP7.5
JP10.2
VSIO
Externally connect to JP 10.1, Effective low
level input, at this time JP10.3 as input common
port. Externally connect to JP10.3, effective
high level input, at this time JP10.1 as input
common port.
JP10.3
G24VIO
input shield power OV, internally connect with
JP7.4
JP11
JP11.1
0V
analog quantity input 0V
JP11.2
AIN-
differential analog quantity input－
JP11.3
AIN+
differential analog quantity input＋
Note：The connection on the load cell is as follows：the sensor simulation quantity output is
connected to JP11.3. the sensor 0V connect to JP11.2 and JP11.1 and JP11.2 should be shorted.
