Steris V-PRO maX 2 - System Symbols

2 — Glossary and Symbols
12
Operator Manual
V-PRO
®
maX 2
10085896_H
• Four bars: 13 - 16 cycles remaining
• Three bars: 9 - 12 cycles remaining
• Two bars: 5 - 8 cycles remaining
• One bar: 1 - 4 cycles remaining
• Zero bars: 0 cycles remaining
Air Ship Cup (PB012):
• Four bars: 4 cycles remaining
• Three bars: 3 cycles remaining
• Two bars: 2 cycles remaining
• One bar: 1 cycle remaining
• Zero bars: 0 cycles remaining
Table 2-1. Approximate Number of Cycles Per Cup
CYCLE
CYCLES PER CUP (PB011) CYCLES PER CUP (PB012)
Standard
(Lumen, Non Lumen, Flexible)
15 4
Fast Non Lumen
30 8
2.3 Symbols
Table 2-2 and Table 2-3 contain symbols which may appear on the Low Temperature Sterilization System.
Table 2-2. Definition of Symbols on Sterilization System
Symbol
Definition
Protective Earth (Ground)
Electrostatic Sensitive Device
Electric Shock Hazard
Attention, Consult Manual for Further Instructions
1-4
129376-417 Operator Manual Listing of Safety Precautions
Symbol Definition
Protective Earth (Ground)
Electrostatic Sensitive Device
Electric Shock Hazard
Sterilization Unit Door Open
Sterilization Unit Door Closed
Locked Cycle or Setup Options
Unlocked Cycle or Setup Options
Attention, Consult Manual for Further Instructions
A Amperage Rating of the Unit
V Voltage Rating of the Unit
~ Alternating Current
Hz Frequency of the Unit
φφ
φφ
φ Phase of the Unit
SNSN
SNSN
SN Serial Number of the Unit
ON
OFF
Oxidizer
Corrosive
3~ Three Phase Alternating Current
Definition of
Symbols
The chart below contains symbols which may be on your Sterilization System:
Corrosive Hazard
