3 — Installation Verification
18
Operator Manual
V-PRO
®
maX 2
10085896_H
Sterilant
• VAPROX HC Sterilant: 59% H
2
O
2
(wt/wt) concentration
EMC
This device complies with: part 15 of the FCC Rules; EN 301 489–1 v2.1.0 (2016–09) and EN 301 489–3 v2.1.1:2017.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
Equipment Drawings
Single Door, Cabinet — 10091243
Single Door, Recessed — 10091523
Double Door, Cabinet — 10091525
Cycle Limits
Table 3-1. Cycle Limits (North America)
Cycle Name Weight Limit
lb (kg)
Device Type
Lumen ID
mm
Lumen
Length mm
Lumens Per
Load
All Cycles See Cycle
Specific
Weight Limits
Non-lumened instruments with
diffusion-restricted spaces
N/A N/A N/A
Non Lumen
Cycle
50 (22.7)
Non-lumened instruments including
non-lumened general medical
instruments, non-lumened rigid, semi-
rigid and flexible endoscopes
N/A N/A N/A
Fast Non
Lumen (if
equipped)
11 (5)
Non-Lumened instruments and non-
lumened rigid, semi-rigid, and flexible
endoscopes.
N/A N/A N/A
Flexible Cycle
24 (11)
Two single- or dual-channeled flexible
endoscopes
≥ 1.0 ≤ 1050
N/A
One single- or dual-channeled flexible
endoscope and additional lumened and
non-lumened instruments
• Flexible Scope
• Additional Instruments
≥ 1.0 ≤ 1050
N/A
≥ 0.48 ≤ 100
5
Lumen Cycle
19.65 (8.9)
Single-, Dual-, or Triple-channeled
stainless-steel medical instruments
≥ 0.77 ≤ 527
20 Lumens
≥ 0.8 ≤ 542
≥ 0.48 ≤ 100
Rigid non-metallic lumens
≥ 3.0 ≤ 298
≥ 4.0 ≤ 424
