Connecting wiring
For connecting wiring, observe the terminal specifications in the chapter FMC 1,5 -ST-3,5
[}232].
Cable requirements
Feature All sizes
Max. cable length 30m
Tab. 127: Cable length [m]
10.5.15 X103: BE6 – BE9
The binary inputs 6 to 9 are available on terminal X103.
X103 for binary signals
For the evaluation of binary signals at X103, observe the technical data of the drive controller;
see the chapter Binary inputs [}47].
Terminal Pin Designation Function
5|4|3|2|1
1 BE6 Binary inputs
2 BE7
3 BE8
4 BE9
5 DGND Reference ground; not bridged with X101, pin
5
Tab. 128: X103 connection description for binary signals
X103 for encoders
If you would like to use X103 as an encoder connection, note the technical data of the evaluable
encoders at X103; see the chapter X103 for encoders [}63].
Information
Note that a master encoder must be connected to axis A or terminal X101.
Single-ended HTL incremental encoders
Terminal Pin Designation Function
5|4|3|2|1
1 BE6 —
2 BE7 N channel
3 BE8 A channel
4 BE9 B channel
5 DGND Reference ground; not bridged with X101, pin
5
Tab. 129: X103 connection description for single-ended HTL incremental signals, axis B
