12.1.2 Protocols and ports for communication using routers
For communication using routers, the protocols and ports used by DriveControlSuite and the
SATMICL communication service must be enabled in the routers, if applicable.
Protocol Port Use Program/service
UDP/IP 37915 Connection test (inquiry) SATMICL service
UDP/IP 37916 Node search SATMICL service
UDP/IP 30001 Primary port for
connection response
(response)
SATMICL service
30002 – 39999 Alternative ports for
connection response
(response)
UDP/IP 40000 Primary port for IP
address specification
DriveControlSuite
40001 – 50000 Alternative IP address
specification ports
TCP/IP 37915 Data transmission DriveControlSuite
Tab. 168: Protocols and ports for a direct connection
12.2 Direct connection
A direct connection is a network connection in which all nodes are in the same network.
In its simplest form, a direct connection is a point-to-point cable connection between the
network interface of the PC where DriveControlSuite is installed and the network interface of the
drive controller. Switches or routers can also be used in place of a simple network cable.
The IP address required for direct connection is either assigned automatically by
DriveControlSuite or using DHCP, or it is specified manually.
Prerequisites
§ The socket of the gateway device and the network connection of the PC must have IP
addresses from the same subnet
§ For setting up the direct connection automatically, the parameter A166 from
DriveControlSuite must be set to 2: DHCP + DS6
12.3 Fieldbus
Detailed information about the fieldbus connection can be found in the corresponding manual,
see chapter Detailed information [}245].
