6.9 Braking resistor
In addition to the supply modules, STOBER offers braking resistors in the various sizes and
performance classes described below. For the selection, note the minimum permitted braking
resistors specified in the technical data of the supply modules. In the event of a fault, such as a
defective brake chopper, the supply module must be disconnected from the power supply.
6.9.1 Braking resistor assignment – PS6
Type KWADQU FZZMQU FGFKQU
ID No. 56634 56635 56636
PS6A24 (—) (X) X
PS6A34 (—) (X) X
Tab. 62: Braking resistor assignment to PS6 supply module
X Recommended
(X) Possible
(—) Useful under certain conditions
— Not possible
6.9.2 KWADQU flat resistor
Properties
Specification KWADQU 420×91
ID No. 56634
Type Flat resistor with temperature switch
(incl. mounting bracket)
Resistance [Ω] 100
Power [W] 600
Thermal time constant τ
th
[s] 60
Pulse power for < 1s [kW] 13
U
max
[V] 848
Cable design FEP
Cable length [mm] 500
Conductor cross-section [AWG] 14/19
(1.9 mm²)
Weight [kg] Approx. 2.6
Protection class IP54
Test symbols
Tab. 63: KWADQU 420×91 specification
