13 | Diagnostics STOBER
218
02/2019 | ID 442728.05
13.3.34 Event 79: Motor / position monitor
The possible effects depend on the configured level (U28).
§ 0: Inactive
§ 1: Message
§ 3: Fault
The drive controller is interrupted if:
§ A29 = 0: Inactive for STOBER device controller
or
§ A540 = 0: disable drive, motor is free to rotate for CiA device controller
Response:
§ The power unit is disabled and axis movement is no longer controlled by the drive controller
§ The brakes are no longer controlled by the drive controller and engage in the event of an
inactive release override (F06)
The drive controller is interrupted with a quick stop if:
§ A29 = 1: Active for STOBER device controller
or
§ A540 = 2: slow down on quick stop ramp for CiA device controller
Response:
§ The axis is stopped by a quick stop; meanwhile, the brakes are controlled by the drive
controller and remain released
§ At the end of the quick stop, the power unit is disabled and axis movement is no longer
controlled by the drive controller; the brakes are no longer controlled by the drive controller
and engage in the event of an inactive release override (F06)
Cause Check and action
Connection error Check the connection and shielding and correct them if necessary
Slip Check the mechanics between the motor and position encoder and
maximum permitted slip and correct them if necessary (I291, I292)
Mechanical damage Check the mechanics between the motor and position encoder and
correct any damage if necessary
Tab. 217: Event 79 – Causes and actions
