Stober PS6A34 - Weight; DC Link Connection; General Technical Data; Tab. 42 SI6 Weight [G]

6 | Technical data STOBER
54
02/2019 | ID 442728.05
6.3.4 Weight
Type Weight without packaging [g] Weight with packaging [g]
SI6A061 2980 4600
SI6A062 3460 5060
SI6A161 3880 5260
SI6A162 4820 6240
SI6A261 4760 6180
SI6A262 6240 7420
SI6A361 6180 7360
Tab. 42: SI6 weight [g]
6.4 DC link connection
The following section contains specifications for the electrical data, dimensions and weight of
DL6B Quick DC-Link modules.
6.4.1 General technical data
The following information applies to all Quick DC-Link modules and corresponds to the general
technical data for the base device.
Device features
Protection class of the device IP20
Protection class of the installation
space
At least IP54
Tab. 43: Device features
Transport and storage conditions
Storage/
transport temperature
−20°C to +70°C
Maximum change: 20K/h
Relative humidity Maximum relative humidity 85%, non-condensing
Vibration (transport) in accordance
with DIN EN60068-2-6
5Hz ≤ f ≤ 9Hz: 3.5mm
9Hz ≤ f ≤ 200Hz: 10m/s²
200Hz ≤ f ≤ 500Hz: 15m/s²
Tab. 44: Transport and storage conditions
Operating conditions
Surrounding temperature during
operation
0°C to 45°C with nominal data
45°C to 55°C with derating −2.5%/K
Relative humidity Maximum relative humidity 85%, non-condensing
Installation altitude 0m to 1000m above sea level without restrictions
1000m to 2000m above sea level with −1.5%/100m derating
Pollution degree Pollution degree 2 in accordance with EN 50178
Vibration (operation) in accordance
with DIN EN 60068-2-6
5Hz ≤ f ≤ 9Hz: 0.35mm
9Hz ≤ f ≤ 200Hz: 1m/s²
Tab. 45: Operating conditions
