Resolver
Specification Resolver signals
U
2
−10V
DC
to +10V
DC
I
2max
80mA
f
2
7 – 9kHz
P
max
0.8W
Transfer ratio 0.5 ± 5%
Number of poles 2, 4 and 6
Signal shape Sinus
Max. cable length 100m, shielded
Tab. 56: Specification for resolver signals
HIPERFACE DSL encoders
Specification HIPERFACE DSL
U
2
12V
DC
I
2max
250mA
Encoder design Single-turn and multi-turn
Max. cable length 100m, shielded
Tab. 57: Specification for HIPERFACE DSL
Unsuitable encoder models
The following STOBER encoder models may not be connected:
Encoder model Code according to type designation
ECI 1118 C0
EQI 1130 Q0
ECI 1319 CR
EQI 1329 QP
EQI 1331 QR
Tab. 58: Encoder models with unsuitable supply voltage range
