7 | Project configuration STOBER
84
02/2019 | ID 442728.05
For each device group, another two insulation end sections are needed for the left and right
termination of the Quick DC-Link modules (ID No. 56659, 2 pieces).
The quick fastening clamps for fastening the copper rails and an insulation connection piece are
included in Quick DC-Link's scope of delivery.
All delivered components (drive controllers, supply modules and accessories) are marked to
make it easy to assign connected components (e.g. assignment of a terminal set to the drive
controller or supply module).
You can find other available accessories in the chapter "Accessories."
Copper rails
Each device group requires 3 copper rails (DC+, DC−, grounding). The copper rails (EATON
CU12X5 034121) with a standard length of 1500 mm must be ordered from STOBER under the
ID No. 56676.
The required length of the copper rails corresponds to the total length of the group minus 5mm:
§ V = Number of DL6B20 × 45mm
§ W = Number of DL6B21 × 65mm
§ X = Number of DL6B10 × 45mm
§ Y = Number of DL6B11 × 65mm
§ Z = Number of DL6B12 × 105mm
Total length = V + W + X + Y + Z − 5mm
Ensure that the length of at least 3 of the ordered copper rails is sufficient for the calculated total
length. During installation, the copper rails must be cut to the actual length of the device group,
see the chapter Length of copper rails [}94].
