12 | Diagnostics STOBER
126
05/2019 | ID 442790.01
12 Diagnostics
LEDs on the top and front give you initial information about the device state of the respective device as well as the states of
the physical connection and the communication. In the event of an error or fault, you will receive detailed information
through the DriveControlSuite commissioning software.
12.1 Drive controller
STOBER drive controllers have diagnostic LEDs that visually indicate the state of the drive controller as well as the states of
the physical connection and communication.
3
2
1
5
4
Err
Run
FSoE
Fig.22: Positions of the diagnostic LEDs on the front and top of the drive controller
1 Fieldbus state
2 FSoE state
3 Drive controller state
4 Service network connection
5 Fieldbus network connection
