5 | Technical data STOBER
50
05/2019 | ID 442790.01
5.8.2 Flat resistor GVADU, GBADU
Type GVADU 210×20 GBADU 265×30 GBADU 335×30
ID No. 55441 55442 55443
SC6A062 X X —
SC6A162 (X) (X) X
SC6A261 (X) (X) X
Tab. 52: Assignment of GVADU, GBADU braking resistor – SC6 drive controller
X Recommended
(X) Possible
— Not possible
Properties
Specification GVADU 210×20 GBADU 265×30 GBADU 335×30
ID No. 55441 55442 55443
Type Flat resistor Flat resistor Flat resistor
Resistance [Ω] 100 100 47
Power [W] 150 300 400
Therm. time const. τ
th
[s] 60 60 60
Pulse power for < 1s [kW] 3.3 6.6 8.8
U
max
[V] 848 848 848
Cable design Radox FEP FEP
Cable length [mm] 500 500 500
Conductor cross-section [AWG] 18/19
(0.82 mm²)
14/19
(1.9 mm²)
14/19
(1.9 mm²)
Weight [g] 300 950 1200
Protection class IP54 IP54 IP54
Test symbols
Tab. 53: GVADU, GBADU specification
