15.4.6 Communication requirements
Note the following requirements for the direct connection.
15.4.6.1 Personal firewall
For communication, both DriveControlSuite and the SATMICL communication service must be enabled in the PC's firewall.
Test communication is initiated during the installation of DriveControlSuite that opens a dialog box for enabling
communication in case of an activated firewall. Note that operation on public networks must also be enabled for
communication using mobile network adapters.
The required setup file can be found in the STOBER Download Center at
http://www.stoeber.de/en/download.
Program/service Path
DS6A.exe
(DriveControlSuite)
Standard installation:
C:\Program Files (x86)\STOBER\DriveControlSuite\bin
Parallel installation of different versions (version 6.X-X):
C:\Program Files (x86)\STOBER\DriveControlSuite (V 6.X-X)\bin
SATMICLSVC.exe
(SATMICL service)
32-bit Windows 7 or 32-bit Windows 10:
C:\Windows\System32
64-bit Windows 7 or 64-bit Windows 10:
C:\Windows\SysWOW64
Tab. 201: Programs and services
15.4.6.2 Protocols and ports for communication using routers
For communication using routers, the protocols and ports used by DriveControlSuite and the SATMICL communication
service must be enabled in the routers, if applicable.
Protocol Port Use Program/service
UDP/IP 37915 Connection test (inquiry) SATMICL service
UDP/IP 37916 Node search SATMICL service
UDP/IP 30001 Primary port for connection
response (response)
SATMICL service
30002 – 39999 Alternative ports for
connection response
(response)
UDP/IP 40000 Primary port for IP address
specification
DriveControlSuite
40001 – 50000 Alternative ports for IP
address specification
TCP/IP 37915 Data transmission DriveControlSuite
Tab. 202: Protocols and ports for a direct connection
