STOBER 5 | Technical data
05/2019 | ID 442790.01
39
5.2 DC link connection
The following section contains specifications for the electrical data, dimensions and weight of the DL6B modules Quick DC-
Link.
5.2.1 General technical data
The following information applies to all Quick DC-Link modules and corresponds to the general technical data for the base
device.
Device features
Protection class of the device IP20
Protection class of the installation space At least IP54
Tab. 30: Device features
Transport and storage conditions
Storage/
transport temperature
−20°C to +70°C
Maximum change: 20K/h
Relative humidity Maximum relative humidity 85%, non-condensing
Vibration (transport) in accordance with DIN
EN60068-2-6
5Hz ≤ f ≤ 9Hz: 3.5mm
9Hz ≤ f ≤ 200Hz: 10m/s²
200Hz ≤ f ≤ 500Hz: 15m/s²
Fall height for freefall
6
Weight < 100kg
in accordance with DIN EN61800-2
(or DIN EN 60721-3-2:1997, class2M1)
0.25m
Tab. 31: Transport and storage conditions
Operating conditions
Surrounding temperature during operation 0°C to 45°C with nominal data
45°C to 55°C with derating −2.5%/K
Relative humidity Maximum relative humidity 85%, non-condensing
Installation altitude 0m to 1000m above sea level without restrictions
1000m to 2000m above sea level with −1.5%/100m derating
Pollution degree Pollution degree 2 in accordance with EN 50178
Vibration (operation) in accordance with DIN
EN 60068-2-6
5Hz ≤ f ≤ 9Hz: 0.35mm
9Hz ≤ f ≤ 200Hz: 1m/s²
Tab. 32: Operating conditions
5.2.2 Assignment of DL6B to SC6
DL6B is available in the following designs suitable for the individual drive controller types:
Type DL6B10 DL6B11
ID No. 56655 56656
SC6A062 X —
SC6A162 — X
SC6A261 — X
Tab. 33: Assignment of DL6B to SC6
6
Only valid for components in original packaging
