15 Appendix
15.1 Terminal specifications
Relevant information for projecting the connecting wiring can be taken from the following chapters.
DIN EN 60204-1 contains basic recommendations that should be taken into account when selecting conductors. The
chapter "Conductors and cables" provides specifications for the maximum current carrying capacity of conductors based on
the way they are laid as well as tips for derating, for example in the case of increased surrounding temperatures or lines
with multiple loaded individual conductors.
WARNING!
Risk of personal injury or material damage due to electric shock and thermal overload!
â–ª Prepare the conductor ends according to the terminal specifications.
â–ª In the case of pre-made cables and conductors, check the conductor ends and adjust them if necessary.
15.1.1 Overview
The following tables clarify which specifications must be observed for which connections depending on the type of drive
controller and accessory.
Drive controllers
Type X2A, X2B X10 X11, X300 X20A, X20B X21 X22 X101, X103
SC6A062 BCF 3,81 180
SN [}189]
GFKC 2,5 -
ST-7,62
[}190]
BLDF 5.08
180 SN
[}190]
GFKC 2,5 -
ST-7,62
[}190]
GFKIC 2.5 -
ST-7.62
[}191]
ISPC 5 -
STGCL-7,62
[}192]
FMC 1,5 -
ST-3,5
[}189]
SC6A162 SPC 5 -
ST-7,62
[}191]
SPC 5 -
ST-7,62
[}191]
ISPC 5 -
STGCL-7,62
[}192]
ISPC 16 -
ST-10,16
[}192]
SC6A261
Tab. 191: Terminal specifications for the base device
Safety technology
Type X12
SR6 BCF 3,81 180 SN [}189]
Tab. 192: Terminal specifications of the safety technology
