STOBER 12 | Diagnostics
05/2019 | ID 442790.01
139
12.2.5 Event 34: Hardware fault
The drive controller is interrupted:
§ The power unit is disabled and axis movement is no longer controlled by the drive controller
§ The brakes are no longer controlled by the drive controller and engage in the event of an inactive release override
(F06)
Number Cause Check and action
1: FPGA
–
12: Timer control board
Defective drive controller Exchange drive controller; fault cannot be
acknowledged
23: FPGA
–
30: Internal power supply
Defective drive controller Exchange drive controller; fault cannot be
acknowledged
Tab. 151: Event 34 – Causes and actions
12.2.6 Event 35: Watchdog
The drive controller is interrupted:
§ The power unit is disabled and axis movement is no longer controlled by the drive controller
§ The brakes are no longer controlled by the drive controller and engage in the event of an inactive release override
(F06)
The brake chopper and brake release override are non-functional while the runtime system restarts.
Number Cause Check and action
1: Core 0 – 2: Core 1 Microprocessor at full load Check the runtime utilization using the scope
image (E191) and reduce it using a longer cycle
time if necessary (A150)
Microprocessor faulted Check the connection and shielding and correct
them if necessary; replace the drive controller
if necessary
Tab. 152: Event 35 – Causes and actions
