9-20 SPARCstation 5 Model 110 Service Manual • November 1996
FIGURE 9-18 System Board Cable Connections
5. Loosen the two captive Phillips screws that secure the system board to the rear of
the chassis.
See
FIGURE 9-19.
FIGURE 9-19 Rear Panel Captive Screws
6. Pull the board out of the back of the chassis until it clears the plastic card guide.
See
FIGURE 9-20. Place the board on an antistatic surface.
Speaker/LED
Diskette data connector
connector
SCSI data connector
DC power connector
CD-ROM audio
connector
Captive screw
Captive screw
