11-4 SPARCstation 5 Model 110 Service Manual • November 1996
FIGURE 11-3 Removing the Extractor From the SBus Card
5. Insert the legs of the card extractor into the holes on the faulty SBus card.
See
FIGURE 11-4. Use two extractors for a double-width card.
SBus card
extractor
Replacement
SBus card
