Chapter 11 System Board and Component Replacement 11-15
FIGURE 11-14 DSIMM Slot Locations on the System Board
5. To eject the faulty DSIMM, press down on the ejection levers on both sides of the
DSIMM connector.
See
FIGURE 11-15.
FIGURE 11-15 Ejecting a DSIMM
6. Holding the DSIMM by its edges, remove it from the slot and place it on an
antistatic surface.
DSIMMs
Slot 7 – J0403
Slot 6 – J0402
Slot 5 – J0401
Slot 4 – J0400
Slot 3 – J0303
Slot 2 – J0302
Slot 1 – J0301
Slot 0 – J0300
Push down ejector levers
to eject DSIMM
