Sun Microsystems SPARCstation 5 Model 110 - FIGURE 9-11 Replacing the Diskette Drive

Chapter 9 Storage Devices 9-13
5. Install the diskette drive outer filler panel by inserting the bottom tabs into the
corresponding slots in the chassis, and rotating the panel upward into position.
FIGURE 9-11 Replacing the Diskette Drive
6. If there is a CD-ROM drive, reinstall it. Otherwise, replace the CD-ROM drive
filler panel.
See
FIGURE 9-8. If you need to install the CD-ROM drive, see Section 9.2.2 “Replacing
the CD-ROM Drive.”
7. Detach the wrist strap and replace the cover.
See Chapter 7.
8. Power on the system.
See Section 6.2 “Powering On the System.”
P4
DC power
cable
Diskette
data cable
