4-8 SPARCstation 5 Model 110 Service Manual • November 1996
FIGURE 4-2 DSIMM Slot Locations
TABLE 4-4 Physical Memory Address Ranges for Slots
1
0 Through 7
1. Each memory slot can contain one DSIMM up to 32 megabytes in size. Slot 0 must have a DSIMM present.
Slot SIMM # Physical Memory Address Ranges
0 J0300 0000 0000 through 01FF FFFF
1 J0301 0200 0000 through 03FF FFFF
2 J0302 0400 0000 through 05FF FFFF
3 J0303 0600 0000 through 07FF FFFF
4 J0400 0800 0000 through 09FF FFFF
5 J0401 0A00 0000 through 0BFF FFFF
6 J0402 0C00 0000 through 0DFF FFFF
7 J0403 0E00 0000 through 0FFF FFFF
SIMM slot J0301
SIMM slot J0302
SIMM slot J0303
SIMM slot J0400
SIMM slot J0401
SIMM slot J0402
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
SIMM slot J0300 Slot 0
SIMM slot J0403 Slot 7
