B-8 SPARCstation 5 Model 110 Service Manual • November 1996
This connector is used to connect the system audio output to a stereophonic
amplifier and external loudspeakers.
B.7.3 Audio Line-In Connector
FIGURE B-10 Audio Line-in Connector
This connector is used to connect external stereophonic sound sources such as a
compact disc player or cassette tape player to the system.
B.7.4 Microphone Connector
FIGURE B-11 Microphone Connector
This connector is used to connect the SunMicrophone™ II (or other suitable
microphone) to the system.
Note – The SPARCstation 5 microphone port accepts stereophonic input; however,
the SunMicrophone II is a monophonic device. Note also that the older
SunMicrophone is not compatible with the SPARCstation 5 system.
B.8 13W3 Video Connector
FIGURE B-12 shows a 13W3 video connector. The 13W3 connector’s pin assignments
and functions are described in
TABLE B-8. The connector is built into the SBus or S24
frame buffer card.
