1-2 SPARCstation 5 Model 110 Service Manual • November 1996
FIGURE 1-1 Basic SPARCstation 5 System
1.1.1 Subassemblies, Boards, and Components
The SPARCstation 5 system unit accommodates the following subassemblies, boards,
and components:
■ System board
■ DSIMMs (up to 8)
■ S24 graphics card
■ SBus cards (up to 3)
■ Hard disk drives, 3.5-inch, 88.0-mm, single-connector (up to 2)
■ CD-ROM drive
■ Diskette drive (3.5-inch)
■ Power supply (150-watt with 2 fans)
1.1.2 Interior View
FIGURE 1-2 shows an interior view of the major subassemblies and the system board
for the SPARCstation 5 system.
