8-6 SPARCstation 5 Model 110 Service Manual • November 1996
FIGURE 8-3 Speaker/Power LED Cable Connections
7. Carefully free the speaker/LED harness from the card guide cable clips, and lift
the harness out of the system chassis.
8.2.2 Replacing the Speaker/LED Cable
1. Feed the LED cable through the chassis wall opposite the light pipe.
See
FIGURE 8-4. Position the replacement LED cable so that the LED just fits inside the
entrance of the LED light pipe.
2. Press the LED cable between the tabs to secure it in place.
See
FIGURE 8-4.
Speaker/LED
cable connector
Power LED
Speaker cable
connectors
Card guide cable clips
on chassis floor
Metal cable clips
