Sun Microsystems SPARCstation 5 Model 110 - FIGURE 4-1 Power Supply Connector; TABLE 4-2 Power Supply Connector Pin Assignments

4-4 SPARCstation 5 Model 110 Service Manual • November 1996
FIGURE 4-1 Power Supply Connector
TABLE 4-2 shows the pin assignments on the power supply connector.
TABLE 4-2 Power Supply Connector Pin Assignments
Pin Color Description
1
1. All volts are direct current.
Pin Color Description
1 Blue +12V 10 Black Ground
2 Brown –12V 11 Black Ground
3 Red +5V 12 Black Ground
4 Red +5V 13 Black Ground
5 Red +5V 14 Black Ground
6 Red +5V 15 Black Ground
7 Red +5V 16 Green AC Outlet
8 Red +5V 17 Purple Fan
9 Grey Power off 18 Yellow Power on
19
10 18
2
11 1314 1612 15 17
3456 87
