Sun Microsystems SPARCstation 5 Model 110 - Twisted-Pair Ethernet Connector; FIGURE B-4 Twisted-Pair Ethernet Connector; TABLE B-4 Pinout for Twisted-Pair Ethernet Connector

B-4 SPARCstation 5 Model 110 Service Manual • November 1996
B.4 Twisted-Pair Ethernet Connector
FIGURE B-4 Twisted-Pair Ethernet Connector
10 N/C 23 Ground
11 N/C 24 Ground
12 N/C 25 N/C
13 N/C 26 Ground
TABLE B-4 Pinout for Twisted-Pair Ethernet Connector
Pin Description Pin Description
1 Transmit Data + 5 N/C
2 Transmit Data - 6 Receive Data -
3 Receive Data + 7 Presence detect
4 N/C 8 Presence detect
TABLE B-3 Pinout for Attachment Unit Interface (AUI) Micro-D Connector (Continued)
Pin Description Pin Description
18
