Sun Microsystems SPARCstation 5 Model 110 - FIGURE 8-4 Routing the LED Cable

Chapter 8 Major Subassemblies 8-7
FIGURE 8-4 Routing the LED Cable
3. Route the LED cable between the diskette drive bracket and the chassis wall and
secure it beneath the metal cable clips on the chassis floor.
See
FIGURE 8-3.
4. Connect the speaker/LED cable to the speaker connectors.
See
FIGURE 8-7.
5. Reinstall the CD-ROM drive (if necessary).
See Section 9.2.2 “Replacing the CD-ROM Drive.”
6. Carefully secure the speaker/LED cable under the card guide cable clips.
See
FIGURE 8-3.
7. Connect the speaker/LED connector to the system board.
See
FIGURE 8-3.
8. Detach the wrist strap and replace the cover.
See Chapter 7.
Press LED cable between
LED light pipe
tabs to secure it in place.
