Chapter 8 Major Subassemblies 8-11
FIGURE 8-7 Speaker Connectors
8.3.2 Replacing the Internal Speaker
Caution – Do not touch the black inner surface of the speaker. Handle the speaker
only by the metal frame to avoid damage.
1. Pull the speaker end of the speaker/LED cable through the speaker opening in the
chassis wall.
2. Unpack the replacement speaker.
3. Slide the fast-on connectors at the end of the speaker/LED cable onto the
terminals of the replacement speaker.
See
FIGURE 8-7.
Note – One connector and terminal pair is larger than the other. They are sized
differently to ensure proper connection.
4. Install the speaker within the opening on the left front of the system chassis and
secure it with the two screws removed earlier.
See
FIGURE 8-6.
Small fast-on
connector
Large fast-on
connector
Speaker
Rear View
