Sun Microsystems SPARCstation 5 Model 110 - S24 Frame Buffer Card; FIGURE 11-8 Closing the Sbus Card Retainers

11-8 SPARCstation 5 Model 110 Service Manual • November 1996
FIGURE 11-8 Closing the SBus Card Retainers
5. Push the card retainers forward to clamp down the SBus card.
See
FIGURE 11-8.
6. Detach the wrist strap and replace the cover.
See Chapter 7 “.
7. Power on the system.
See Section 6.2 “Powering On the System.”
11.2 S24 Frame Buffer Card
The S24 frame buffer card plugs in to the AFX Bus slot shown in FIGURE 11-9.
Close both
card retainers.
