Sun Microsystems SPARCstation 5 Model 110 - Audio Ports; Audio Line-Out Connector; FIGURE B-7 Audio Ports; FIGURE B-8 Headphone Connector

Appendix B Input/Output Connectors B-7
B.7 Audio Ports
FIGURE B-7 Audio Ports
B.7.1 Headphone Connector
FIGURE B-8 Headphone Connector
This connector is used to connect a set of stereophonic headphones to the system for
private listening of audio output.
B.7.2 Audio Line-Out Connector
FIGURE B-9 Audio Line-out Connector
TABLE B-7 Signals for the SPARCstation 5 Audio Ports
Headphone Line-Out Line-In Microphone (new)
Tip Left Channel Left Channel Left Channel Left Channel
Ring (Center) Right Channel Right Channel Right Channel Right Channel
Shield Ground Ground Ground Ground
