Chapter 11 System Board and Component Replacement 11-5
FIGURE 11-4 Installing the SBus Card Extractor
6. Hold both ends of the card extractor. Pull upward slowly until the connector is
detached from the slot.
See
FIGURE 11-5 and FIGURE 11-6.
FIGURE 11-5 Removing a Single-Width SBus Card
Install card
extractor.
